Listing is for:
1x Pair of rear toe arms (Bucket style)

Introducing the GKTech 370Z/V36 Skyline rear toe buckets (rear mid links), an OEM style suspension arm for those that want to retain the separate spring and shock design. They replace the OEM 5" helical style spring with a common off the shelf 2.5" race style spring to ensure compatibility and ease of spring rate adjustment.

These arms feature a laser-cut, CNC folded, and TIG welded sheet metal design, ensuring durability and a sleek appearance. Crafted from 4130 chromoly steel, each component has undergone extensive Finite Element Analysis (FEA) testing couple with countless days of drift and grip track abuse to guarantee

One standout feature is the double adjuster, allowing for effortless on-car alignment adjustments. With an impressive adjustment range of -22mm to +30mm, achieving optimal suspension settings has never been easier.

Alongside this, we've incorporated standard sized PTFE lined spherical bearings, effectively eliminating any deflection present in OEM bushings. This addition significantly improves compliance, resulting in more precise control during challenging manoeuvres. Moreover, our thoughtfully designed Delrin spring locator retains the spring while eliminating any unwanted spring noise.

Specs:

- Suits race style 2.5" ID closed and ground springs

- Laser cut, CNC folded and TIG welded sheet metal design

- Made from 4130 chromoly steel
- FEA tested for strength

- Double adjuster for easy on-car alignment adjustments
- Adjustment range of -22mm to +30mm

- standard PTFE lined spherical bearings

- Delrin spring locator

Notes

** Spring perch between spring and chassis required for locating and adjusting spring   **

** Only suits 2.5" ID race style springs **

Recommended spring lengths:
GKTECH Rear Upright - 225mm (9")
OEM Rear Upright        - 200-225mm (8-9")

Suits:
Nissan
RZ34 Z
V36 SKYLINE Coupe (2008-2013 Only)/ Sedan (2009-2013 Only)
Z34 370Z
